Features: High Definition: AHD signal output, supports 720P/1080P resolution.
Superior Night Vision: Built-in 5 IR LEDs with IR-CUT auto switch for clear night imaging.
Waterproof & Durable: IP67-rated protection, suitable for harsh weather conditions.
Wide Temperature Range: Operating temp: -20℃ ~ 75℃;
Storage temp: -30℃ ~ 85℃. Auto Adjustment: Auto white balance, backlight compensation, and AGC for optimal image in varying light.
Wide-Angle Lens: Standard 2.8mm lens with 110° horizontal view (customizable up to 150°).
Low Power Consumption: Only 58mA operating current, 150mA when IR is activated.
Standard Connector: 4-pin aviation plug for easy and reliable installation.
| Car Fitment | Toyota - Europe Truck |
| Function | Waterproof, NIGHT VIEW |
| Voltage | 9-36V |
| Model Number | RD-DC806B |
| Brand Name | HOPE |
| Type | Reverse Camera, Monitor, Backup camera |
| Resolution | 1080P |
| Sensor | 1/2.9＂AHD 1080P CMOS |
| Format | PAL/NTSC (Option) |
| Frame Rate | 25fps |
| Effective Pixels | 1920（H）×1080（V） |
| Vertical synchronization frequency | 50Hz; 60Hz |
| minimum illumination | 0.001Lux |
| Video Output | 1.0VP-P/75Ω |
| SNR(Signal to Noise Ratio) | ≥46dB |
| AGC | Auto |
| White Balance | Auto |
| BLC | Auto |
| lens | 2.8mm ,Customizable up to 150 ° |
| Effective Angle of the lens | Horizontal Angle: 110° |
| Night-vision effect | Infrared night vision IR-CUT automatic switching |
| Light board, audio | 850nm 5-lamp board, does not support audio |
| Video interface | AHD |
| Working current | 58mA±5%, infrared start-up 150mA±5% |
| Light q'ty | 6 lights |
| Working temperature | -20℃~ 75℃ |
| Storage temperature | -30℃~ 85℃ |
| Waterproofing grade | IP 67 |
| Position | Rear |
| Warranty | 1 Year |
| Net weight | 135g |
| Packing size | 135*85*55mm |
| Place of Origin | Guangdong, China |
* The product specifications listed above are indicative only. For full details and technical documents, please reach out to our customer support.
