Features:
High Definition: AHD signal output, supports 720P/1080P resolution.
Waterproof & Durable: IP68-rated protection, suitable for harsh weather conditions.
Wide Temperature Range: Operating temp: -20℃ ~ 75℃; Storage temp: -30℃ ~ 85℃.
Wide-Angle Lens: angle up to 120°.
Wide Voltage：9-36V
IR Distance：10-15M
| Model Number | RD-DC002 |
| Brand Name | HOPE |
| Type | Reverse Camera, Backup camera, Monitor |
| Resolution | 720P; 1080P |
| TV system | PAL/NTSC (Option) |
| Light Compensation | Infrared |
| Waterproof | IP68 |
| Electronic Shutter | 1/50-1/100000S,1/60-1/100000s |
| Minimum Illumination | 0.01 Lux / F1.2 |
| AGC | Auto |
| White Balance | Auto |
| Backlight Compensation | Auto |
| Signal Output | AHD |
| Video Output | 1.0V P-P/75Ω |
| Connector | RCA or 4Pin (Option) |
| Signal to Noise Ratio | ≥46dB |
| Mirror/Normal Image Adjustable | Adjustable |
| Parking Line | Triple Colors (Option),Adjustable |
| Current Consumption | ≥150mA |
| Power | ≥2W |
| Operating Temperature | –20℃ ~ 75℃ |
| Storage Temperature | –30℃ ~ 85℃ |
| cover material | metal |
| Product packaging | Color box,135*85*55mm |
| Place of Origin | Guangdong, China |
* The product specifications listed above are indicative only. For full details and technical documents, please reach out to our customer support.
