IP68 camera
BSD
Wireless
Night vision
Wide angle
Introduction to Applicable Models
IP67 screen
IP68 camera
BSD
Wireless
Night vision
Wide angle
Loop recording
9-36V
Features:
Operating frequency: 2400MHz~2483.5MHz wireless camerasystem adopts the FHSS technology to guarantee the privacyand anti-interference of connection.
the signal can reach 400mIn open areas,
| Model Number | DC820 |
| Brand Name | HOPE |
| Type | Reverse Camera, Backup camera, Monitor |
| Resolution | 720P; 1080P |
| Image Sensor | 1/2.9＂GC2053 CMOS |
| TV system | PAL/NTSC (Option) |
| Light Compensation | Infrared |
| View Angle | 70°；95° |
| Waterproof | IP68 |
| Electronic Shutter | 1/50-1/100000S,1/60-1/100000s |
| AGC | Auto |
| White Balance | Auto |
| Backlight Compensation | Auto |
| Signal Output | AHD |
| Video Output | 1.0V P-P/75Ω |
| Connector | RCA or 4Pin (Option) |
| Signal to Noise Ratio | ≥46dB |
| Mirror/Normal Image Adjustable | Adjustable |
| Parking Line | Triple Colors (Option),Adjustable |
| Current Consumption | ≥150mA |
| Power | ≥2W |
| Operating Temperature | –20℃ ~ 75℃ |
| Storage Temperature | –30℃ ~ 85℃ |
| Product packaging | Color box,135*85*55mm |
| Place of Origin | Guangdong, China |
* The product specifications listed above are indicative only. For full details and technical documents, please reach out to our customer support.
